Product Application Guide

TEAFLEX has been at the forefront of producing performance corrugated polyamide flexible conduits for civil, industrial & other specialized markets. With a wide range of application specific products, TEAFLEX today produces over 20 different types of corrugated polyamide flexible conduits, each specially built to perform to the highest standard. With UL flexible conduits, the product line is suitable for global operations. Download the detailed product application guide to help you choose the right product for your application.

Product Features: (Some features may vary for select items) • Suitable for continuous use in both indoor and outdoor installations • Produced in specially formulated polyamide namely PA6, PA12, PP, POL & PVDF as per application requirements • Halogen & Cadmium free as per DIN 53474 • Excellent UV & weather resistance as per ISO 4982-2 • Enhanced mechanical strength for high impact & compression strength as per IEC EN 61386 • Excellent flexibility & fatigue strength • Fire resistant as per industry standards with low smoke self extinguishing properties • Resistant to oils, grease, mild acids & alkaline solutions • Certified to RU, UL, EN 61386-23, EN 45545-2 (HL2) & EN 45545-2 (HL3) amongst other application specific certifications • Wide range of operating temperature with maximum up to 175°C • Glow wire test index of 850°C as per EN 60695-2-10 • Compliant to RoHS-3 and WEEE standards

www.teaflex.com

Terms Of Sale

Privacy Policy

Warranty

Sitemap

SERIES : ECO Flexible corrugated polyamide conduit built for general purpose industrial and commercial use. • Halogen and cadmium free formulated polyamide PA6, built in Black or Gray • Sizes range from NW-7 up to NW-95 (Metric 10mm to 106mm) • Good weather and UV resistance with continuous operating temperature range of -40°c to 105°C • Can handle short term exposure (168 hours) to temperatures up to 140°C • Good compression strenght, flexibility and good resistance to mild acids, oils, greases and alkalies • Flame retardent class of UL94 HB with Oxygen Index of >/= 25% (EN ISO 4589) • cRUUs listed and certified as per IEC EN 61386-23

SERIES : SMP Flexible corrugated polyamide conduit built for medium duty industrial and transportation markets. • Halogen and cadmium free formulated polyamide PA6, built in Black or Gray • Sizes range from NW-7 up to NW-95 (Metric 10mm to 106mm) • High weather and UV resistance with continuous operating temperature range of -40°c to 105°C • Can handle short term exposure (168 hours) to temperatures up to 150°C • High impact & fatigue strenght, excellent flexibility and excellent resistance to mild acids, oils, greases and alkalies • Flame retardent class of UL94 V2 (low smoke) with Oxygen Index of >/= 28% (EN ISO 4589) • Fire Protection Class of HL2 as per Railway Standard EN 45545-2 • cRUUs listed and certified as per IEC EN 61386-23. Tested to ASTM E162 - E662, ASTM E1354, BOEING BSS 7239 and BOMARDIER SMP 800-C standards

SERIES : UCV UCP UCF Flexible corrugated polyamide conduit built for heavy duty industrial, machine tools and transportation markets. • Halogen and cadmium free formulated polyamide PA6, built in Black or Gray • Sizes range from NW-17 up to NW-48 (Metric 20mm to 50mm) • High weather and UV resistance with continuous operating temperature range of -40°c to 105°C • Can handle short term exposure (168 hours) to temperatures up to 150°C • High impact & fatigue strenght, high flexibility and excellent resistance to mild acids, oils, greases and alkalies • Flame retardent class of UL94 V2 (low smoke) with Oxygen Index of >/= 28% (EN ISO 4589) • Fire Protection Class of HL2 as per Railway Standard EN 45545-2 • cULUs listed and certified as per IEC EN 61386-23

SERIES : LTP Flexible corrugated polyamide conduit built for heavy duty use in building of ships, railway cars and public buildings, where enhanced flame retardency is a must. • Halogen and cadmium free formulated polyamide PA6, built in Black or Gray • Sizes range from NW-7 up to NW-48 (Metric 10mm to 50mm) • High weather and UV resistance with continuous operating temperature range of -40°c to 105°C • Can handle short term exposure (168 hours) to temperatures up to 150°C • High impact & fatigue strenght, high flexibility and excellent resistance to mild acids, oils, greases and alkalies • Flame retardent class of UL94 V0 (low smoke) with Oxygen Index of >/= 33% (EN ISO 4589) • Fire Protection Class of HL3 as per Railway Standard EN 45545-2 • Smoke emission class F2 as per NF F16-101-102, Fire class l2 as per NF F16-101 and classified as S4/SR2/ST2 as per DIN 5510-2 • Certified as per IEC EN 61386-23

SERIES : HCP Flexible corrugated polyamide conduit built for heavy duty use in machine building, railway equipments process equipments, where enhanced abrasion strength & chemcial resistance is required. • Halogen and cadmium free formulated polyamide PA6, built in Black or Gray • Sizes range from NW-7 up to NW-95 (Metric 10mm to 106mm) • High weather and UV resistance with continuous operating temperature range of -40°c to 105°C • Can handle short term exposure (168 hours) to temperatures up to 150°C • High impact & fatigue strenght, high flexibility and excellent resistance to mild acids, oils, greases and alkalies • Flame retardent class of UL94 V2 (low smoke) with Oxygen Index of >/= 28% . (EN ISO 4589) • cRUUs listed and certified as per IEC EN 61386-23

SERIES : HT Flexible corrugated polyamide conduit built for heavy duty use in machine building and automotive products like cars, buses and trucks, where high temperature & moisture resistance is required. • Halogen free formulated Thermoplastic Co-Polyester Elastomer (TPC), built in Orange. Other colors on request, subject to minimum order quantity • Sizes range from NW-12 up to NW-48 (Metric 16mm to 50mm) • High weather and UV resistance with continuous operating temperature range of -40°c to 150°C • Can handle short term exposure (3000 hours) to temperatures up to 175°C • High impact & fatigue strenght, excellent flexibility and high resistance to mild acids, oils, greases and alkalies • Flame retardent class of UL94 V2 (low smoke) with Oxygen Index of >/= 29% (EN ISO 4589) • Smoke emission class F2 as per NF F16-101-102, Fire class l3 as per NF F16-101 • Tested for 150 days in water @ 85°C for resistance properties to the Hydrolysis phenomenon • Certified as per IEC EN 61386-23

SERIES : RSP Flexible corrugated polyamide conduit built for heavy duty use in machine building, robotic equipments and automation systems, where high abrasion resistance and excellent flexibility is required. • Halogen and cadmium free formulated polyamide PA12, built in Black or Gray • Sizes range from NW-7 up to NW-95 (Metric 10mm to 106mm) • Good weather and UV resistance with continuous operating temperature range of -50°c to 95°C • Can handle short term exposure (168 hours) to temperatures up to 175°C • High impact & fatigue strenght, excellent flexibility and good resistance to mild acids, oils, greases and alkalies • Flame retardent class of UL94 V2 (low smoke) with Oxygen Index of >/= 28% (EN ISO 4589) • Certified as per IEC EN 61386-23

SERIES : PADC Flexible corrugated polyamide divisible conduit built for retrofit and cable harness applications for industrial use. • Halogen and cadmium free formulated polyamide PA6, built in Black • Sizes range from NW-10 up to NW-45 with Ingress Protection rating of IP54 • Good weather and UV resistance with continuous operating temperature range of -40°c to 100°C • Can handle short term exposure (168 hours) to temperatures up to 130°C • Good impact & fatigue strenght, high flexibility and good resistance to mild acids, oils, greases and alkalies • Flame retardent class of UL94 V2 , self extinguishing type • Certified as per IEC EN 61386-23, as applicable for certain properties

Data is given for illustration purposes only and does not absolve the end user from independent application suitability tests.

Listed below are only some of our most common variants. For additional options, please write in to us with your specifications.
